Circuit breaker 16A 1P+N

Circuit breaker 16A 1P+N
НОВ Препоръчан

Описание

device application
Distribution

range
Acti 9

product name
Acti 9 iC60

product or component type
Miniature circuit-breaker

device short name
IC60N

poles description
1P + N

number of protected poles
1

neutral position
Left

[In] rated current
16 A

network type
DC
AC

trip unit technology
Thermal-magnetic

curve code
B

breaking capacity
10 kA Icu conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz
20 kA Icu conforming to EN/IEC 60947-2 - 100...133 V AC 50/60 Hz
6000 A Icn conforming to EN/IEC 60898-1 - 230 V AC 50/60 Hz
36 kA Icu conforming to EN/IEC 60947-2 - 12...60 V AC 50/60 Hz

utilization category
Category A conforming to EN 60898-1
Category A conforming to IEC 60898-1

suitability for isolation
Yes conforming to EN 60947-2
Yes conforming to IEC 60947-2
Yes conforming to EN 60898-1
Yes conforming to IEC 60898-1

standards
EN 60898-1
IEC 60947-2
EN 60947-2
IEC 60898-1

Коментари

39,90 лв.
Моля, първо изберете разновидност.
SKU
Няма наличност

Детайли

Описание

device application
Distribution

range
Acti 9

product name
Acti 9 iC60

product or component type
Miniature circuit-breaker

device short name
IC60N

poles description
1P + N

number of protected poles
1

neutral position
Left

[In] rated current
16 A

network type
DC
AC

trip unit technology
Thermal-magnetic

curve code
B

breaking capacity
10 kA Icu conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz
20 kA Icu conforming to EN/IEC 60947-2 - 100...133 V AC 50/60 Hz
6000 A Icn conforming to EN/IEC 60898-1 - 230 V AC 50/60 Hz
36 kA Icu conforming to EN/IEC 60947-2 - 12...60 V AC 50/60 Hz

utilization category
Category A conforming to EN 60898-1
Category A conforming to IEC 60898-1

suitability for isolation
Yes conforming to EN 60947-2
Yes conforming to IEC 60947-2
Yes conforming to EN 60898-1
Yes conforming to IEC 60898-1

standards
EN 60898-1
IEC 60947-2
EN 60947-2
IEC 60898-1

Коментари

Сподели
